NEW (made-to-order) Gur-is Moonstep Technology System, High Performance, Side Seal Bag Making Machine

Gur-is Moonstep Technology System, High Performance, Side Seal Bag Making Machine

» German Made Beckhoff Brand Industrial PC, 4 pcs. Servo Motors and Servo Drive System

» Bag length, set number can be changed via screen. Bag counting, machine speed can be seen on the screen

» There is one photocell. Ability to produce printed bags and none-printed bags

» Ability to work with OPP, PP, CPP, High Density Poly Ethylene (HDPE), Low Density Poly Ethylene (LDPE) and Recycled Polyethylene materials

» The machine would stop and give information on the screen when `Roll is empty`, `The print mark is not right position`

» The pneumatic ballerina system with motor and invertor in order to unwind the roll

» Servo motor controlled synchronous roller system

» The belt motor speed is also adjusted via invertor

» The rotating lower jaw is included to the machine as standard

TY-650 MT / TY-750 MT / TY-850 MT / TY-1050 MT
Max. Bag Length(mm) / 650 / 750 / 850 / 1050
Bag Width (mm) / 80-800 / 80-800 / 80-800 / 80-800
Thickness of Film(mm) / 0,020-0,100 / 0,020-0,100 / 0,020-0,100 / 0,020-0,100
Servo Motor(pieces) / 4 / 4 / 4 / 4
Production Speed (pieces/min) / 300 / 300 / 300 / 300
Total Air Consumption(liter/min) / 200 / 250 / 300 / 350
Total Installed Power(kW) / 15 / 15 / 15 / 15
